Fenwal 35-715615-011 Microprocessor-Based Direct Spark Ignition Control Module with Inducer Blower Relay

Fenwal 35-715615-011 Microprocessor-Based Direct Spark Ignition Control Module with Inducer Blower Relay
Images for general purposes only. Actual may be different than depicted.
Fenwal 35-715615-011 Microprocessor-Based Direct Spark Ignition Control Module with Inducer Blower Relay

Fenwal 35-715615-011 Microprocessor-Based Direct Spark Ignition Control Module with Inducer Blower Relay

SKU: 35-715615-011
Rating:
* This Product is Now Obsolete
No Replacement Available
0
$0.00
0
$0.00
0

The 35-71 is a 120 VAC direct spark ignition (DSI) control designed for use in all types of gas-fired appliances. The control uses a microprocessor circuit to provide precise, repeatable timing and operating sequences. On-board diagnostics with LED output makes troubleshooting easy and ensures safe and efficient operation.

FEATURES

  • Safe start with DETECT-A-FLAME® flame sensing technology
  • Custom pre-purge and inter-purge timings
  • Inducer blower control and airflow switch monitoring
  • Single or three trials for ignition
  • System diagnostic LED
  • Flame current test points
  • Local or remote flame sensing
  • Automatic reset
  • Alarm output (normally closed contact)
  • Open board, potted or enclosure
  • Polarity insensitive input power

APPLICATIONS

  • Commercial cooking
  • Agriculture
  • Infrared burners
  • Construction heaters
  • Other gas-fired appliances

Agency Certifications

SPECIFICATIONS

  • Recognized under the UL component program, UL 372. Software certified to ANSI/UL 1998. UL File MH8817
  • Design Certified to ANSI Z21.20, CAN/CSA C22.2 No. 199-M89
